Heavy galvanized stone filled gabion basket for flood protective

Brief Description:

Gabion are made of heavily galvanized, double twisted, steel woven wire mesh. Material Galvanized, pvc coated Popular sizes 2.7/ 3.4/ 2.2mm 8x10cm 2x1x1m 2.2/ 2.7/ 2.2mm 6x8cm 2x1x0.3m Connection method Lacing wire C ring

Send Email to Us Download PDF

Product Detail

Product Tags

Specifications:

(1)Hole size: 60 * 80mm, 80 * 100mm, 80 * 120mm, 100 * 120mm, 120 * 150mm(2) Wire:mesh wire, edge wire, and binding wire
(3) wire tension: no less than 38kg/m2 380N/mm
(4) surface treatment
1. Electrogalvanizing.The maximum amount of zinc is 10g/m2.Anticorrosion sex difference
2. Hot galvanizing.The maximum amount of zinc can reach 300g/m2.Strong anticorrosion
3. Galfan (zinc aluminum alloy).It is divided into two materials: zinc-5% aluminum – mixed rare earth alloy wire, zinc – 10% aluminum mixed rare earth alloy wire.Superprotective strength
4. PVC plastic coated.The thickness of the package is usually 1.0mm thick, for example: 2.7mm and 3.7mm.
(5) partition: add a partition to each meter in the long direction of the cage net
(6) size: can be customized
(7) the range of aperture and silk diameter.

Hexagonal Gabion Reno Mattress Wire Materials: Quality Galvanized Wire, Galfan Wire etc.

Hexagonal Gabion Reno Mattress sizes: 1x1x0.5m,1x1x1m, 2x1x0.5m, 2x1x1m, 3x1x1m, 3x1x0.5m, 4x1x0.5m, 4x1x1m, 6x2x0.3m,Custom orders available.

Hexagonal Gabion Reno Mattress Mesh Size:60*80mm, 80*100mm,100*120mm, 120*150mmCustom orders available.

Hexagonal Gabion Reno Mattress Surface Treatment: Finish can be hot-dipped galvanized, galvanized aluminum alloy or PVC coated, etc.

We guarantee high quality gabion mesh, make sure all our products are flat surface, refined aperture, strong structure and corrosion-resistance to protect the dam and rivebank.

SPECIFICATIONS
Gabion Boxes 80x100mm 100x120mm 120x150mm	Mesh Wire Dia.	2.70mm	Zinc coating: >260g/m2
	Edge Wire Dia.	3.40mm	Zinc coating: >275g/m2
	Tie Wire Dia.	2.20mm	Zinc coating: >240g/m2
Mattress 60x80mm	Mesh Wire Dia.	2.20mm	Zinc coating: >240g/m2
	Edge Wire Dia.	2.70mm	Zinc coating: >260g/m2
	Tie Wire Dia.	2.20mm	Zinc coating: >240g/m2
Special sizes are available.	Mesh Wire Dia.	2.00~4.00mm
	Edge Wire Dia.	2.70~4.00mm
	Tie Wire Dia.	2.00~2.20mm
